2026 ASV, POSI-TRACK VT100 FORESTRY Skid Steers - Track, 2026 ASV VT100 Max-Series Track Skid Steer (Ask about our rent to own options) OperationsLoader ArmsVerticalOperating Weight11570 lbsRated Operating Capacity @ 35%4100 lbsGround Pressure4.1 psiEngine Power103.5 hpLoader ArmsVerticalOperating Weight11570 lbsGround Pressure at Operating Weight4.1 psiRated Operating Capacity (35% Of Tipping Load)4100 lbsTipping Load11714 lbsTravel Speed, Maximum9.3 mphEngineTypeDiesel 4-cylinder, Intercooled TurboModelYanmar 4TNV94FHTCooling SystemHydraulically-driven fan and anti-freeze filled radiator cooling systemIntake Air CleanerThree-stageEmission ControlsMeets all U.S. EPA Tier 4 final standardsEngine Power103.5 hpDisplacement3.1 LGross Horsepower103.5 hpTorque Peak291 ft-lbDrive TrainTrack TypeGeneral purpose track constructed of rubber compound with embedded co-polymer cords and all-purpose treadsDrive SystemTwo hydrostatic direct drive sprockets controlled by a single joystickTrack Drive SprocketElevated with low friction, replaceable sprocket rollersUndercarriage SuspensionTwo independent torsion axles per undercarriageRoller Wheels24 high-density polyurethane and rubber wheels per track. Wheels include sealed bearingsTrack Width20 in.Length of Track on the Ground71 in.Ground Contact Area2845 in.2Roller Wheel Diameter Front & rear wheels15 inRoller Wheel Diameter Middle Wheel10 inAuxiliary HydraulicControlsIntermittent via joystick button or continuous via console switch. High-flow is adjustable.CouplersFlat Faced Couplers: 1/2 in. low flow, 3/4 in. high flowCooling SystemHigh efficiency side-by-side radiator and oil coolerPump Capacity Low23 gpmPump Capacity High41 gpmSystem Pressure Max Low3481 psiSystem Pressure Max High3989 psiElectrical SystemStandard FeaturesBlock heaterOutlets1 -12 V port inside operator stationWiringUpgradeable wiring harnessCharging System80 amp alternatorNominal Charge12 VBattery950 CCAOperator StationSeatMechanical suspension seat with 2 in. seat beltControlsElectronic joystick controls with ISO or H pattern settings, adjustable operator profiles and speedsCabAll Weather Cab with curved glass doorEngine SpeedStandard foot pedal with hand dial optionFOPSISO 8083-ForestryROPSROPS: ISO 8082-ForestryOPSISO 8084-Forestry, BC WCB G603 - Window guards for forestry, BC WCB G604 - Light duty screen guards for off highway, BC WCB G608 - Heavy duty roof structure, ISO 6683 - Seat belt anchors, CAL OSHA 1596 - Seat belt, ISO 11839 - Forestry thrown object guardIllumination2 - Forward-facing LED lights, 2 - Rear-facing LED lightsStandard FeaturesAll Weather Cab, Forestry cab with all sides polycarbonate, air ride seat, 3/4 in. poly door, Level 2 FOPS, Forestry Guarding package, reversing fan, 20 in. tracks, rear view camera, adjustable pilot controls, 7-in. color deluxe display, roof panel,
