2027 Eby Maverick 16'x6'11"x6'7" 14K, Livestock Trailers, The all-new, all-updated Eby Maverick is built for those who never stop pushing the limits. With bold styling and a modern, chiseled profile, it delivers the perfect balance of strength, performance, and attention to detail. Every feature is designed with efficiency and safety in mind, including smooth interior walls, no wheel pockets, a slam-shut rear gate, and a high-grip diamond plate floor.
SLAT-SIDE
LIVESTOCK TRAILER
Modern styling and premium features
• 7"x5" rear frame corner posts
• Slam shut tailgate
• Easy low-step threshold
• No interior fender wells
• Smooth slat interior walls
• High grip diamond plate floor
• All new tapered side posts
Standard Sizes:
Lengths:  16', 20', 24', 30'
Width: 6'11"
Heights: 6'7", 7'1", 7'7"

Floor Lengths 16', 20', 24', 30'
Outside Width 6'11"
Inside Height 6'7", 7'1", 7'7"
GVWR 14,000 lbs - 2 (7,000 lb axles)
25,000 lbs - 3 (7,000 lb axles)
Axles 7,000# Rubber Torsion
Wheels 16" × 6" Heavy-duty steel, 8-lug
Tires 235/80R16 Load Range E
Brakes 12" × 2" Electric, Self Adjusting
Safety Equipment Two chains and electronic break-away kit
Nose Double wall construction
Coupler 2-5/16" Ball coupler (20,000# ball rating) with steel hitch
post section and aluminum front gusset, adjustable height
Side Wall 7" extruded aluminum slats on 1" × 4-1/4" posts on 24"
centers
Floor .115 6061T-6 aluminum diamond plate with (4) 1" high
ridges
Side Door 33" Wide, curb side escape door
Rear Door Slam shut full-swing with (3) 4" extruded aluminum offset
hinges for extended swing radius; 32" sliding door on
roadside
Roof Sheet One-piece .040 aluminum
Partition Center divider with outside release
Lights LED inside and out; 12-volt D.O.T. approved
